The portable SD 400 Oxi L handheld meter allows the determination of dissolved oxygen using the highly accurate optical luminescence technology

SD 400 OXI L



Features:

  • Luminescence technology
  • High accuracy
  • No need of an internal electrolyte: no additional effort, no hidden costs
  • No sample flow necessary for stable sensor response
  • No interferences from other gases
  • Drift-free measurement ensures extremely precise results
  • Low wear and low maintenance due to a long-life membrane head
  • Ready for immediate use without warm-up or polarisation times

Description:



The SD 400 Oxi L uses optical luminescence technology. Your advantage: High measuring accuracy, fast response and absolutely user-friendly measuring.Thanks to luminescence technology, no electrolyte is needed. Regular refilling is therefore no longer necessary - and maintenance is reduced to a minimum. The electrode of the SD 400 Oxi L is optimized for standard BOD bottles (NS 19/26). The device is therefore ideally suited for standard-compliant BOD determination of the dilution BOD. By means of integrated software ("data logger") the collection and analysis of data is simplified.

Functions such as the automatic temperature, pressure and salt compensation are ideal to match individual measuring conditions and make the instrument the perfect all-rounder in water analysis. Calibration data are sensor-specific and stored on the integrated SD card in the unit, which also contains a free software for monitoring, storing and transferring measurement data.

Measuring Range
Concentration: Oxygen 0 - 50 mg/l, Saturation: 0 - 500 %, Temperature: -5 to 50 °C, Presure: 51 to 112 kPa
Display
Large LCD display with backlight
power supply
Micro-USB 4 batteries (AA)
Portability
Portable
Compliance
CE
Dimensions
98 x 54 x 162 mm
Weight
330 g (unit incl. batteries)
Protection Class
IP 67 (Sensor)
Accuracy
Concentration - < 20 mg/l: ± 1% MW oder 0,1 mg/l, > 20 mg/l: ± 10% MW, Saturation: < 200 %: ± 1% MW oder 0,1 % > 200 %: ± 10% MW, Temperature: ± 0,2 °C
Measurement principle
Optical DO
