The BD 600 is a respirometric system for the determination of Biochemical Oxygen Demand (BOD).Save time, reduce the potential for errors and easily interpret data to help make process control decisions for your plant.

BIOLOGICAL OXYGEN DEMAND - BD 600



Application:

  • Waste Water Treatment

Features:

  • User friendly
  • Large brillant graphic display
  • Graphical representation of measured values
  • USB & SD Card interface
  • Easy and quick interpretation of measurement values

Description:

The BD 600 is the ideal system for process control or as a secondary test to the Dilution Method. Using a respirometric system solves many of the issues associated with the dilution method for BOD analysis. It's easy to begin collecting data - simply add sample to the bottle, add nitrification inhibitor and place the sensor head on the bottle. Measurements are automatically taken and stored at regular time intervals and can be recalled at your convenience - no more weekend trips to the lab or plant. In addition to displaying results of a sample directly in mg/L BOD, the large, integrated, display is able to display the BOD curve which makes it is easy to see and understand measurement data points and trends. In addition, each sensor head has an integrated LED. This allows operators to visually confirm which sample the data is being displayed for and reduces potential confusion or errors over which sample data is presented

The BD 600 interface, makes it easy to assign an identification code or sample name when setting up a new sample. This helps track a sample from the time it is collected and ensures traceability during sample measurement.

Measuring Range
0-40, 0-80, 0-200, 0-400, 0-800, 0-2000, 0-4000 mg/l
Display
Backlit
power supply
100 - 240 V / 50-60 Hz 3 alkali-manganese batteries (Baby cells/ size C)
Portability
Benchtop
Protection Class
IP 53
Compliance
CE EMC according to DIN EN 61326
Dimensions
181 x 230 x 375 mm
Weight
4.1 kg (4100 g, unit with bottles & batteries 5775 g, complete with stirring unit)
